VP-CLASS

VP-CLASS.

The specialists in vacuum applications

The VP machine range with integrated vacuum chamber is specifically designed for evacuation
possibilities across the entire mould area.


The clamping unit consists of a bolted plate structure, the vertical side plates of which simultaneously
act as walls for the vacuum chamber.


A vacuum system consisting of vacuum pump(s) and a vacuum tank ensures rapid and effective
evacuation. Alternatively, other combinations can also be used if required.


  • Clamping force ........................................................... 1,100 to 6,300 kN
  • Injection volumes ......................................................... 160 to 8,500 cm3
  • Heating platen size ............................ 400 x 500 mm to 810 x 1,000 mm
