H-CLASS

H-CLASS.

Horizontal machines for automated production

We offer machines in a horizontal design either in a traditional column version (HS) or with a tiebarless C-frame clamping unit (HC).


An outstanding feature of the HC range, with its up to 100 ton clamping force, is the tiebarless design of the clamping unit. This is based on the proven C-frame clamping unit and offers free access to the mould area for rapid mould change of the integration of automation devices.


The machines from the HS range, from 160 ton clamping force, are based on a clamping unit in 4-column design, equipped with a fully-hydraulic clamping system. Through the use of a large pressure piston, force will be brought evenly into the mould.


Large distances between the bars offer good access to the mould for rapid mould changes and the use of large heating platen. The increased daylight is particularly well-suited for the use of brush units and other handling devices.


  • Clamping force ................................................................ 500 to 6,300 kN
  • Injection volumes............................................................. 50 to 8,500 cm3
  • Daylight............................................................................. 475 to 915 mm
  • Heating platen size ............................. 400 x 400 mm to 810 x 1,000 mm
